17" LCD Chassis Aluminum Portable Wide Temp. LCD display w/ Intel Core i7- 4770 Haswell 3.4GHz 8MB Cache Quad Core Support SBC with Backplane (Model: BPCW1730WTS-i7)
17" LCD Chassis Aluminum Portable Wide Temp. LCD display w/ Intel Core i7- 4770 Haswell 3.4GHz 8MB Cache Quad Core Support SBC with Backplane (Model: BPCW1730WTS-i7)
X
Inquiry/Quote Request
- Overview
- Download
Typical Applications
- Rugged Aluminum Construction with shock absorbing rubber corners
- 17” LCD display with tempered glass, 1280x 1024 16.7M, 300 nits brightness, MTBF: 50,000 hrs
- Designed for Standard ATX M/B/ SBC with Backplane
- Offer 7/ 10 full length slots expansion capability
- NB type multi-languages keyboard with touchpad
- PS2 650W power supply, 100~240VAC
- Offer 1x 5.25”, 1x slim DVD-RW, 2x 3.5” drive bays
- Carrying case to manage portable PC with ease
| Model No | BPCW1730WT-i7 | BPCW1730WTS-i7 |
| Motherboard | Support ATX M/B | Support SBC with Backplane |
| Slots | Offer 7 expansion slots | Offer 10 expansion slots |
| Drive bay | 1x 5.25”, 1x slim DVD-RW, 2x 3.5” | |
| Display | 17" LCD Display, 1280x 1024, 300 nits brightness 16.7M colors, 800:1, MTBF:50,000 hours Anti-reflection tempered strengthen glass | |
| VGA | AD conversion board, DVI interface (Option VGA) | |
| KB/MS | Laptop type, multi-languages Keyboard/ touchpad | |
| Power Supply | PS2, 650W, 100~240VAC, Auto switch | |
| Construction | Rugged Aluminum Construction with rubbercorners | |
| Speaker | Built-in amplified 3W speakers | |
| Dimension | 433Wx 346Hx 227D mm (17.05”x 13.62”x 8.9”) | |
| Weight | 12 kgs | |
| Carrying Case | Padded carrying case with wheels | |
Environmental Factors
| Operating | Non-Operating | |
| Temperature | -20°C~70°C (-4°F~158°F) | -20°C~80°C (-4°F~176°F) |
| Relative Humidity | 10%~90% | 10%~95% |
| Shock | 10g, 11ms, half-Sine | 30g, 11ms, half-Sine |
| Vibration | 10-500Hz (0.4 Grms) | 10-500Hz (1.12 Grms) |
| Approval | CE, FCC, RoHS | |
