19" Industrial Touch LCD Monitor (Model:CCH1900-TRB)
- Overview
- Download
19" Wide-Screen Industrial Grade LCD Integrated Touch Screen w/ USB Controller (Model:CCH1900-TRB)
X
Inquiry/Quote Request
Product discontinues. Contact us at Info@iTechLCD.com for replacement item.
(This product is Non-Returnable)
Wide-screen Industrial - Grade 19.0" integrated Touch Screen LCD monitor designed for desktop and VESA arm-mount applications.
It utilizes a 19.0? (16X9) widescreen diagonal color TFT LCD as Industrial grade display and a integrated resistive touch screen as input device. Touch screen communication to CPU is RS232 or USB.
| Industrial LCD Display Specifications | ||
| General | ||
Display Type |
Flat Panel Display: TFT Active Matrix |
|
Display Area |
Diagonal: 19.0" widescreen | |
Width |
17.3 in | |
Depth |
8.1 in | |
Weight |
10.1 lbs | |
Features |
Ambix, NaViSet , Rapid Response, No Touch Auto Adjust, Cable management cover, AccuColor Control Systems | |
Software Type |
NaViSet, Drivers & Utilities | |
| Image | ||
Dot Pitch |
0.284 mm | |
Color Support |
Up to 16.2 million colors | |
Image Brightness |
300 cd/m2 | |
Resolution |
1440 x 900 (max) | |
Max vertical view angle |
+85/-75 | |
Max Horizontal view angle |
+85/-85 | |
Max sync rate (V x H) |
76 Hz x 81 KHz | |
| Video Input | ||
Digital Video Standard |
Digital Visual Image (DVI) | |
Analog Video Signal |
RGB | |
| Audio Output | ||
| Speaker | Stereo - integrated | |
| Weight | ||
| Unit | 23.1 lbs. (w/ stand) | |
| 15.4 lbs. (w/o stand) | ||
| Power Requirements | ||
Voltage |
AC 110/240 V ( 50/60 Hz ) | |
Consumption |
On: 50W Power Savings Mode: 2W |
|
| Operating Conditions | ||
Temperature |
+41° F to +95° F | |
Humidity |
10% to 80% | |
Touch Screen Typical Specifications
| COMMERCIAL Touch Screen | INDUSTRIAL Touch Screen | MILITARY Touch Screen | |
| Mechanical | |||
| Actuation Force* | 20-500 grams | 20-500 grams | 20-500 grams |
| Actuation Travel | 0.05 mm | 0.05 mm | 0.05 mm |
| Thickness (w/o sup.) | 0.50 mm | 0.50 mm | 0.50 mm |
| Thickness (w/sup.) | 2 mm (min) | 2 mm (min) | 2 mm (min) |
| Mechanical Life | 36 million + | 36 million + | 36 million + |
| Electrical | |||
| Contact Resistance: | |||
| Open | 20 Meg Ohm | 20 Meg Ohm | 20 Meg Ohm |
| Close | 10-30 K-Ohm | 10-30 K-Ohm | 10-30 K-Ohm |
| Operating Voltage | 5 Volts | 5 Volts | 5 Volts |
| Operating Current | 5 Micro Amp | 5 Micro Amp | 5 Micro Amp |
| ESD Shield | 7 KV Min | 7 KV Min | 7 KV Min |
| Optical | |||
| Light Transmissivity: | |||
| @ 550 Nano Meters | 82%-83% | 82%-83% | 82%-83% |
| Environmental | |||
| Temperature | |||
| Operating & Non-Operating: |
0 to 35°C (32° to 95°F) | -10° to 55°C (14° to 131°F) | -40° to 85°C (-40° to 185°F) |
| Altitude | |||
| Operating & Non-Operating: |
12,000 meters | 12,000 meters | 12,000 meters |
| Vibration | |||
| 0.7G @ 15 Hz | 0.7G @ 15 Hz | 0.7G @ 15 Hz | |
| 1.3G @ 25 Hz | 1.3G @ 25 Hz | 1.3G @ 25 Hz | |
| 3G @ 55 Hz | 3G @ 55 Hz | 3G @ 5 Hz | |
| Shock | |||
| 30G for 11 Mil. Sec. | 30G for 11 Mil. Sec. | 30G for 11 Mil. Sec. | |
| * Using a .375 inch diameter RTV tip. | |||
Installation Manual
Click for download driver
| Windows | Mac | Linux | ||||||||||||||
|
|
|
