15.6" LCD 1000nits Portable Style w/ VGA, DVI, HDMI & USB KB/Mouse, 9-36V DC (Model: AVPW1560HBe-DC)

15.6" 1920 x 1080 LCD 1000nits, All Aluminum Construction with bumper at the corner, Portable Style with VGA+DVI+HDMI with USB keyboard/mouse, Internal 9-36V DC Power module (include a cable 1.8m with V+ and V- terminal)

15.6" 1920 x 1080 LCD 1000nits, All Aluminum Construction with bumper at the corner, Portable Style with VGA+DVI+HDMI with USB keyboard/mouse, Internal 9-36V DC Power module (include a cable 1.8m with V+ and V- terminal)

Inquiry/Quote Request
AVPW1560HBe-DC
  • Overview
  • Specifications
  • Download
The 15-inch Portable Style Rackmount Monitor (AVPW1560HBe-DC) from iTech is a versatile solution for professional rackmount installations. Featuring a high-resolution 15-inch display, this unit is designed to provide exceptional performance in space-constrained environments. Its portable form factor makes it easy to integrate into various industrial or commercial setups. Equipped with a DC power input, this rackmount monitor ensures energy-efficient operation, making it ideal for applications in server rooms, control centers, and more.


Features
  • Rugged aluminum construction with rubber corner bumpers
  • Portable, Folding, Light weight for easy handheld
  • 15.6" widescreen LCD panel
  • 1920 x 1080 support FHD with 1080p resolution
  • high brightness panel - 1000 nits
  • HDMI + VGA + DVI video input
  • Rear 2xUSB 2.0 Type A, Sharing USB peripheral device for computer (ex, flash disk, hard driver, KB/Mouse)
  • 88-key keyboard with touch pad mouse
  • USB 2.0 Keyboard & Mouse
  • Build in 2x 3 watts speakers


Options
  • Display Port input
  • 3G / HD / SD -SDI Broadcast grade input
  • Touchscreen
LCD       Size 15.6"
Backlight LED
Resolution 1920*1080 Full HD (support resolution up to 1920x1200)
Max.color 262K
Luminance 1000cd/m2
View Angel (H/V) 140 /120
Contrast Ratio 650: 1
Video Input HDMI, DVI-D, VGA
USB HUB 2x Rear USB 2.0 Type A for Peripheral USB Device
Touch Screen Yes, for option (Driver needed)
KB/Mouse Emulation USB
Power Internal 9-36V DC Power module (include a cable 1.8m with V+ and V- terminal)
Environment Operation temp: 0 to S0°C
Storage temp: -20 to 60°C
Humidity: 10%-90%, non-condensing
Shock: 10G acceleration ( 11ms duration)
Vibration: 17 to 500Hz 1G PTP
Physical Dimensions / Net Weights 390 mm (W) x 320 mm (D) x 70 mm (H) / 4KG
Packing Dimensions /Gross weights 580 mm (W) x 470 mm (D) x 58 mm (H) / 8KG
Accessory
1.8 meter HDMI Cable, 1.8 meter DVI-D Cable, 1.8 meter VGA Cable, 1.8 meter USB Cable, 1.8 meter Audio Cable (one each)
