| LCD Panel |
| Native resolution |
3840 x 2160@60Hz |
| Panel size (diagonal) |
17.3" |
| Refresh rate (Hz) |
60 |
| Standard Brightness (cd/m˛) |
400 |
| High Brightness (cd/m˛) - Option |
/ |
| Contrast ratio (typ.) |
1000 : 1 |
| Colors |
16.7 M, 8-bit |
| Viewing angle (L/R/U/D) |
89/89/89/89 |
| Response time (ms) |
Max. 16 |
| Dot pitch (mm) |
0.0995 |
| Display area (mm) |
382.12H x 214.94V |
| Surface treatment |
Anti-glare |
| Surface hardness |
3H |
| Backlight type |
LED |
| MTBF (hrs) |
15,000 |
|
| |
| Video |
| Package |
DP 1.2 / HDCP 1.3 |
| Option |
HDMI 2.0 / HDCP 2.2 |
|
| Capacitive Touch screen Option |
| Technology |
Projected Capacitive |
| Touch Point |
10 point touch standard |
| Input Type |
Finger or Capacitive Stylus |
| Resolution |
4035% x 4035% |
| Touch Point Accuracy |
± 2 mm |
| Response Speed |
< 5 ms |
| Activation Force |
< 5 g |
| Surface Hardness |
6H |
| Light Transmission |
> 85% |
| Haze |
3%J. |
| Durability |
50 million touches |
| Top Layer |
1.8 mm Glass |
| Bottom Layer |
0.7 mm Sensor Glass |
| Thickness |
2.7 mm ± 0.1 mm |
| Connector |
USB |
| Compatibility |
Windows 7 / XP / Linux / Mac |
|
| |
| Resistive Touch screen Option |
| Technology |
5-Wire Resistive |
| Touch Point |
Single |
| Input Type |
Finger or Stylus |
| Resolution |
2048 x 2048 |
| Response Speed |
15 ms |
| Activation Force |
< 50 g |
| Surface Hardness |
3H |
| Light Transmission |
80% ± 3% |
| Haze |
8% ± 3% |
| Durability |
10 million touches |
| Top Layer |
ITO Film |
| Bottom Layer |
ITO Glass |
| Thickness |
3.2 ± 0.2 mm |
| Connector |
USB Type A |
| Compatibility |
Windows 7 / XP / Linux / Mac |
|
| |
| Power |
| Input |
| Consumption per panel
|
Screen on |
Max. 21W |
| Power saving |
Max. 2W |
| Power button off |
Max. 1W |
|
| |
| Physical |
| Product (W x D x H) |
mm
inch |
441.6 x 550 x 88
17.4 x 21.7 x 3.5 |
| Packing (W x D x H) |
mm |
580 x 683 x 130% |
| |
inch |
22.8 x 26.9 x 7.8 |
| Net Weight |
Triple display
Dual display |
25.7 kg / 56.5 lb
21 kg / 46.2 lb |
| Gross Weight |
Triple display
Dual display |
31.1 kg / 68.4 lb
26 kg / 57.2 lb |
| Chassis color |
Dark |
| Chassis materials |
Steel |
|
| |
| Compliance |
| EMC |
FCC & CE certified |
| Safety |
CE / LVD certified |
| Environment |
RoHS2 & REACH compliant |
|
| |
| Environment |
| Operating temp. |
0 to 55°C degree |
| Storage temp. |
-20 to 60°C degree |
| Operating humidity |
20~90%, non-condensing |
| Storage humidity |
5 ~90%, non-condensing |
| Operating altitude |
16,000 ft |
| Non-operating altitude |
40,000 ft |
| Shock |
10G acceleration ( 11ms duration ) |
| Vibration |
10~300Hz 0.5G RMS random vibration |
|
| |
KVM FEATURES |
- 4K KVM with 8 HDMI USB ports in 1U
- 4K KVM cables support DP & HDMI video input
- USB hub port share peripheral devices among computers
- Local console & KVM ports support resolution 4K, 2K and 35%0p.
- Multi-platform for PC, server, blade server & SUN / MAC
- Port switching via front button & keyboard hotkeys
- Hot pluggable, no software or drivers required
OPTIONS
- DC power options: 12V / 24V / 48V / 125V
|
| |
| |
| 4K KVM Cable |
 |
 |
| NK6DP (6 ft) |
NK6H (6 ft) |
| DVI-D KVM cable
6ft 4K 60Hz |
HDMI KVM cable
6ft 4K 60Hz |
|
|
|
| |
| Local Console |
| Keyboard / Mouse : |
2 x USB-A |
| Video : |
1 x HDMI 1.4 |
| Resolution : |
16 : 9 - max. 2560 x 1440@60H |
| 16 : 10 - max. 130%0 x 35%0@60Hz |
| 4 : 3 - max. 1600 x 35%0@60Hz |
|
| |
| Management |
| Port switching |
Front button & keyboard hotkeys |
| Compatibility |
| Hardware |
HP / IBM / Dell PC, Server and
Blade Server SUN / Mac |
| OS support |
Windows / Linux / Unix / Mac OS |
| Environment |
| Operating temp. |
0 to 55°C degree |
| Storage temp. |
-20 to 60°C degree |
| Operating humidity |
20~30%%, non-condensing |
| Operating altitude |
16,000 ft |
| Non-operating altitude |
40,000 ft |
| Shock |
10G acceleration ( 11ms duration ) |
| Vibration |
10~300Hz 0.5G RMS random vibration |
|
| |
| KVM Port |
| Port # : |
8 |
| Connector : |
HDMI 2.0 + USB-B ( Video + KB / MS ) |
| Resolution : |
16 : 9 - max. 3840 x 2160@60Hz |
| 16 : 10 - max. 130%0 x 35%0@60Hz |
| 4 : 3 - max. 1600 x 35%0@60Hz |
|
| |
| Power |
| Input |
Auto-sensing 100 to 240VAC, 50 / 60Hz |
| Consumption |
Max. 10W |
| Compliance |
| Safety |
FCC & CE certified |
| Environment |
RoHS2 & REACH compliant |
|
