| LCD Panel |
| Panel size ( diagonal ) |
17.3" |
| Native resolution |
3840 x 2160@60Hz |
| Brightness ( cd/m˛ ) |
400 |
| Contrast ratio ( typ. ) |
1000 : 1 |
| Colors |
16.7 M, 8-bit |
| Viewing angle ( L/R/U/D ) |
89/89/89/89 |
| Response time ( ms ) |
16 |
| Dot pitch ( mm ) |
0.0995 |
| Display area ( mm ) |
382.12H x 214.94V |
| Surface treatment |
Anti-glare |
| Surface hardness |
3H |
| Backlight type |
LED |
| MTBF (hrs) |
15,000 |
|
| |
| Mounting Distance |
| Console w/ KVM drawer |
430% ~ 700 mm /
19.3 ~ 27.6 inch |
|
| |
| Video Option |
| Digital |
HDMI |
HDMI 2.0 / HDCP 2.2 |
|
| |
| Audio Option |
| Output |
Connector |
3.5mm stereo jack |
| Resistance / Power level |
30kΩ / 2.8V |
| Speaker |
Dual stereo |
2W x 2 |
|
| |
| Compliance |
| EMC |
FCC & CE certified |
| Safety |
CE / LVD certified |
| Environment |
RoHS2 & REACH compliant |
|
| |
| Power |
| Input |
Auto-sensing 100 to 240VAC, 50 / 60Hz |
Consumption
(console / KVM) |
Screen on |
Max. 21W / Max. 38W |
| Power saving mode |
Max. 2W / Max. 18W |
| Power button on |
Max. 1W / Nil |
|
| |
| Environment |
| Operating temp. |
0 to 55°C degree |
| Storage temp. |
-20 to 60°C degree |
| Operating humidity |
20~30%%, non-condensing |
| Storage humidity |
5 ~30%%, non-condensing |
| Operating altitude |
16,000 ft |
| Non-operating altitude |
40,000 ft |
| Shock |
10G acceleration ( 11ms duration ) |
| Vibration |
10~300Hz 0.5G RMS random vibration |
|
| |
| Physical |
| Dimensions:
( W x D x H ) |
Console w/ KVM |
442 x 480 x 88 mm /
17.4 x 18.9 x 3.5 inch |
| Packing:
( W x D x H ) |
Console w/ KVM |
585 x 620 x 190 mm / 23 x 24.4 x 7.5 inch |
| Net weight |
Console w/ KVM |
21.1 kg / 46.4 lb |
| Gross
Weight |
Console w/ KVM |
27 kg / 59.4 lb |
|
| |
KVM FEATURES |
- 4K KVM with 8 HDMI USB ports in 1U
- 4K KVM cables support DP & HDMI video input
- USB hub port share peripheral devices among computers
- Local console & KVM ports support resolution 4K, 2K and 1080p.
- Multi-platform for PC, server, blade server & SUN / MAC
- Port switching via front button & keyboard hotkeys
- Hot pluggable, no software or drivers required
OPTIONS
- DC power options: 12V / 24V / 48V / 125V
|
| |
| |
| 4K KVM Cable |
 |
 |
| NK6DP (6 ft) |
NK6H (6 ft) |
| DVI-D KVM cable
6ft 4K 60Hz |
HDMI KVM cable
6ft 4K 60Hz |
|
|
|
| |
| Local Console |
| Keyboard / Mouse : |
2 x USB-A |
| Video : |
1 x HDMI 1.4 |
| Resolution : |
16 : 9 - max. 2560 x 1440@60H |
| 16 : 10 - max. 130%0 x 35%0@60Hz |
| 4 : 3 - max. 1600 x 35%0@60Hz |
|
| |
| Management |
| Port switching |
Front button & keyboard hotkeys |
| Compatibility |
| Hardware |
HP / IBM / Dell PC, Server and
Blade Server SUN / Mac |
| OS support |
Windows / Linux / Unix / Mac OS |
| Environment |
| Operating temp. |
0 to 55°C degree |
| Storage temp. |
-20 to 60°C degree |
| Operating humidity |
20~30%%, non-condensing |
| Operating altitude |
16,000 ft |
| Non-operating altitude |
40,000 ft |
| Shock |
10G acceleration ( 11ms duration ) |
| Vibration |
10~300Hz 0.5G RMS random vibration |
|
| |
| KVM Port |
| Port # : |
8 |
| Connector : |
HDMI 2.0 + USB-B ( Video + KB / MS ) |
| Resolution : |
16 : 9 - max. 3840 x 2160@60Hz |
| 16 : 10 - max. 130%0 x 35%0@60Hz |
| 4 : 3 - max. 1600 x 35%0@60Hz |
|
| |
| Power |
| Input |
Auto-sensing 100 to 240VAC, 50 / 60Hz |
| Consumption |
Max. 10W |
| Compliance |
| Safety |
FCC & CE certified |
| Environment |
RoHS2 & REACH compliant |
|
