2U Rackmount Compact 17" LCD Monitor Keyboard Drawer Cherry Touchpad keyboard (RCK2417ce)

2U Rackmount Compact 17" LCD Monitor Keyboard Drawer Cherry Touchpad keyboard (RCK2417ce)

2U Rackmount Compact 17" LCD Monitor Keyboard Drawer Cherry Touchpad keyboard (RCK2417ce)

RCK2417ce
  • Overview
  • Download

Features

- Monitor and Cherry™ keyboard with two button touchpad occupies 2U of 19” rack space.
- Included adjustable mounting depth ball bearing slides lock in the fully extended position.
- Monitor powers off preserving back light life when tilted down for sliding into the rack.
- Retainer and lock options to keep unit contained in the rack when not in use.
- Housed in rugged steel construction with a durable powder coat finish.
- Reduced rack depth for mounting in confined spaces.


Display Specifications:

Display Type:
Active matrix TFT LCD
Colors Displayed:
16.7 million colors.
Contrast Ratio:
17”: 1000:1 typ.
19”: 800:1 typ.
Brightness:
17”: 250 cd/m2 typ.
19”: 270 cd/m2 typ.
Viewing Angle:
Horizontal (17"/19"): 170o /178o
Vertical (17"/19"): 160o /178o
Response Time:
17”: 5ms Typ.
19”: 18ms Typ.
Resolution:
640 x 350
640 x 480
800 x 600
1024 x 768
1280 x 1024
Display Area:
17” Diagonal
19” Diagonal
Horizontal Frequency:
31 to 80 KHz
Vertical Frequency:
55 to 76 Hz.


Keyboard and Mouse Specification:

Rollover:  Alpha N-key rollover.
Auto repeat: Yes.
Self Diagnostics: At power on and system reset.
Data Buffer: All codes buffered before sending.
Operating voltage: +5 VDC +/- 5%.
Operating current: 200 mA
Touchpad Size: 2.2” X 1.6”
Buttons: Left and Right
Interface: Keyboard: PS/2
Touchpad: PS/2
Compatibility: Windows operating systems.



General Specifications:

Dimensions:
17": 19.0" (W) x 3.50" (H) x 13.25" (D)
19": 19.0" (W) x 3.50" (H) x 14.90" (D)
Weight:
20 lbs
Power (TFT Display):
90 - 260 VAC, 50/60 Hz.
60 Watts maximum
On-Screen Controls:
Brightness, Contrast, Horizontal & Vertical Position, Auto Adjust, OSD H & V Position, Load and Save Values
Plug & Play:
DDC1 and DDC2B
Temperature:
Operating: 0o C to 50o C
Storage: -20o C to 60o C
Humidity:
Operating: 10 to 85% RH (max)
Input Signal (VGA):
R.G.B. analog video, TTL H & V sync
Input Connector:
Display: 15-pin mini D-Shell
Colors Available:
Black(B) and Light Gray
