32" Panel PC IP65 Front LCD Monitor 1920x1080, 400 nits Side OSD, including rear screw/Clamp/VESA Mount with Capacitive Touch (Model: EMCW3200-i5-TC)

32" Panel PC IP65 Front LCD Monitor 1920x1080, 400 nits Side OSD, including rear screw/Clamp/VESA Mount with Capacitive Touch (Model: EMCW3200-i5-TC)

32" Panel PC IP65 Front LCD Monitor 1920x1080, 400 nits Side OSD, including rear screw/Clamp/VESA Mount with Capacitive Touch (Model: EMCW3200-i5-TC)

Inquiry/Quote Request
EMCW3200-i5-TC
  • Overview
  • Download

Features:

  • 32" LCD panel, 1920 x 1080, 400 nits
  • Intel® Core™ i7/i5/i3/ Celeron Processor
  • Intel® H61
  • 2 x DDR3 1333/1600MHz SO-DIMM Slot (up to 16GB)
  • 1 x VGA,1 x HDMI, 2 x COM, 6 x USB2.0
  • 2 x LAN, 1 x PS2, Mic-in, Line-Out

Specifications:


Panel Cell Type / Glass Surface TFT LCD / Black Anti-Glare, low reflection coating
Aspect Ratio / Size wide / 32" viewable diagonal area
Active Area / Pixel Pitch 698.4(H) x 392.9(V) mm / 0.3638(H) x 0.3638(V) mm

Native Resolution / Colors

1920(H) x 1080(V) / 16.7 Million
Brightness / Contrast 400 cd/m (typ) / 3000 : 1
Response Time ^ 8 ms(G-to-G)
Viewing Angle (typical) H. 178° (- 89° ~ + 89°) , V. 178°(- 89° ~ + 89°)
Light Source CCFL, Long life, 50,000 hrs (typ)
System CPU Intel® Core™ i7/i5/i3/ Celeron Processor
BIOS UEFI
System / Graphic Chipset Intel® HD Graphics (By CPU); Shared Memory
System Memory 2 x DDR3 1333/1600MHz SO-DIMM Slot (up to 16GB)
HDD 4 x SATA2
I/O Ports 1 x VGA
2 x COM
1 x HDMI
6 x USB(2.0)
2 x LAN
Audio Line In
Expension 1 x Mini PCI-E (Half Size)
Power Power Input Power Consumption ATX PWR (24+4 pin) ###Watt, <1 Watt
Environmental Operating Temperature Operating Humidity - 5°C~60°C (23°F~140°F) 0%~95% (non-condensing)


Options Touch Enhanced Pane Other
Resistive(With Glass) High Brightness Panel WiFi Networking Digital Signage
Capactive Panel-LED Backlight 3G Web Cam
SAW Wide Temperature Bluetooth Motion Sensor
  Wide Viewing Angle RFID Auto LightSensor
  Sunlight Readable   Auto-Dimming
