15” Black 5WR Serial Touch LCD Monitor (Model: FCH1500-RTS-S)

15” Black 5WR Serial Touch LCD Monitor (Model: FCH1500-RTS-S)

15” Black 5WR Serial Touch LCD Monitor (Model: FCH1500-RTS-S)

FCH1500-RTS-S
  • Overview
  • Specifications
  • Download
Utilizing 5-wire resistive touch technology, the 15 Inch Desktop TouchScreen LCD Monitor is a lightweight touchscreen system that easily fits in almost any situation. The resistive serial and USB touch screen offers a drift-free and accurate interactive touch experience for more than 35 million touches, all for an affordable price. This popular touch LCD monitor is extremely durable and easy to handle with a touch screen sensitive enough for gloved hands. Its small footprint is ideal for space-limited interactive touch environments, such as Point-of-Sale (POS) applications, ATM machines, medical equipment, and industrial process control.

The 15 Inch Desktop TouchScreen LCD Monitor comes in two different models: resistive serial touch screen and resistive USB touch screen. Built from market-leading components from Elotouch and 3M Touch, the 15 Inch Desktop TouchScreen LCD Monitor is built for a durable interactive touch screen experience for system integrators and value-added resellers. Learn more about which 15 Inch Desktop TouchScreen LCD Monitor model is right for you.

Each model features 1024 x 768 touch monitor resolution with a simple on-screen menu system that is DOS-, Windows-, and Linux-compatible. The small open-frame design allows for flexible control mounting on the side or the rear both the resistive serial touch screen or resistive USB touch screen models. Value-added options, such as a Digital Signage Solutions Player , offer even more flexibility, making the 15 Inch Desktop TouchScreen LCD Monitor the complete interactive touch monitor experience!

Features

  • UL, CSA, TUV, FCC B, VCCI B, CE, TCO 99, TUV Ergo, EPA Energy Star certification
  • Plug and Play via standard VGA (DB-15) analog source
  • VESA 75mm x 75mm available
  • Superior viewing angles, contrast ratio, and brightness
  • Sturdy stand for touch screen design
  • Touch Drivers support DOS, Windows, Mac, and Linux operating system

Specifications

Model

FCH1500-RTS-S

FCH1500-RTS-U

Touch Interface serial port USB port
LCD Panel
Display Panel 15 inch TFT LCD
Pixel Pitch 0.297(H) x 0.297(V) mm
Max. Resolution 1024 x 768 XGA
Contrast Ratio 500:1 (typical)
Brightness 240 cd/m2  (typical, 80% of original brightness)
Uniformity 80% (typical)
Backlight MTBF 50,000 hours (typical at 25°C)
Response Time 25 ms (typical)
Display Colors 16 million
Viewing Angle ±70°L/R, ±60°U/D (typical at CR=5)
Video and Power
OSD Controls Brightness, Contrast, Phase, Clock, Color, H&V position, Auto-tune, Recall
Input Signal RGB analog 0.7V peak to peak
Video Input Connector D-sub 15 pin analog
Scan Frequency 24-62kHz horizontal scan, 50-75 Hz vertical refresh
Power Supply AC/DC 12V power adapter, universal 100-240 Volts
Mechanical and Environment
Operating Temperature 0~50°C [32~122°F]
Storage Temperature -20~60°C [-4~140°F]
Humidity 85% (maximum)
Dimensions (WxHxD) 408 x 388 x 201 mm [16.1 x 15.3 x 7.9 inch]
Net Weight 5.9 Kg [13 Lb]

Package Includes

  • 6ft VGA cable
  • 6ft Power cable
  • 6ft Touch cable
  • AC/DC Power Adapter
  • Monitor
  • Touch Driver CD
