7" 1000nits Front IP65 Panel Mount w/ DP+HDMI, Rear OSD, DC 9~36V, Resistive Touch (USB) (Model: YPMW700HBWT-TR-DC)
7" Wide / 6mm Front Aluminum Bezel / Panel mount / Front IP65 / -20 to 70C / 800x480 / 1000nits LED / DP + HDMI input / Rear OSD / DC 9~36V Power input / 110/220V AC external adapter / 4Wires Res. Touch (USB)
X
Inquiry/Quote Request
- Overview
- Specifications
- Download
Features: |
|
| Panel Type | 7-inch TFT LCD |
| Screen Diagonal | 7-inch |
| Active Display Area (mm) | 152.4 (H) x 91.44 (V) |
| Pixel Pitch (mm) | 0.1905 x 0.1905 |
| Number of Pixels | 800x480 |
| Contrast Ratio | 1000:1 |
| Color Arrangement | 262K(6-bit) / 16.2M(8-bit) |
| Brightness (cd/m²) | 1000 cd/m² |
| Viewing Angle(Typ.) | 80/80/80/80 (R/L/U/D) |
| Signal Connector | HDMI + DP |
| Power Source | DC 9~36V power input with External 110/220V AC adapter |
| Power Management | VESA DPMS Compliant |
| Operating Temperature | -20 ~ +70°C |
| Storage Temperature | -20 ~ +70°C |
| Plug & Play | VESA DDC 1/2B |
| Touch Type | 4-Wire Resistive Touch Screen (USB Type A Interface) |
| Transparency | > 80% (typ.) |
| Hardness of surface | 3H |
| Linearity | ±1.5%(max.) |
