7" Wide All-in-one Chassis Fanless Panel-PC (OEM) with Intel Atom E3815 CPU, 5 wire resistive, USB interface, PoE supported (Model: EMCW0700-AT-PoE)

Panel	Cell Type / Glass Surface	TFT LCD / Black Anti-Glare, low refection coating
	Aspect Ratio / Size	Wide / 7" viewable diagonal area
	Active Area / Pixel Pitch	152.40(H) x 91.44(V) mm / 0.1905(H) x 0.1905(V) mm
	Native Resolution / Colors	800(H) x 480(V) / 262 K
	Brightness / Contrast	400 cd/m2 (typ) / 500 : 1
	Response Time	≤ 30 ms
	Viewing Angle (typical)	H. 130° (- 65° ~ + 65°) , V. 110°(- 60° ~ + 50°)
	Light Source	LED backlight, Long life, 35,000 hrs (typ)
Input Sources	PC System	Signal	Analog RGB (0.7/1.0 Vp-p, 75 ohms)
		Sync	Separate Sync, Composite Sync, Sync On Green
		Frequency	Fh : 30 - 82Khz , Fv : 50 -75Hz
	Audio System	2W speaker x 2
Input Terminals	1 x VGA (15 Pin Female D-Sub) , 1 x PC Audio (Stereo Headphone Jack) , 1 x DC Power Plug
Convenient Features	Auto Calibration , Back Light Adjustment , Plug&Play (VESA DDC/CI, DDC 2B)
	OSD Multi-Languages , Wall Mount Ready (VESA Dimension - please refer to Drawing)
Power	12V DC in
Power Consumption	Operation / Power Saving	9.625 watt , < 2 watt (Support DPMS)
Operating Condition	Temperature / Humidity	0°C ~ 50°C (32°F ~ 122°F) , 10% ~ 90% (no condensation)
Storage Condition	Temperature / Humidity	- 20°C ~ 60°C (- 4°F ~ 140°F) , 10% ~ 90% (no condensation)
Certifcation		FCC , CE
Dimensions	Physical	Please refer to Drawing
	Carton	W x H x D = TBD
Weight	N.W. / G.W.	3 Kgs / 4 Kgs
Container Loaded	20ft / 40ft / 40ft HQ	TBD (Sets , By pallet)

Form Factor	Expansion Slots
Proprietary	1 x Full-size Mini-PCIe slot
100(W) x 108.5(D) mm	Internal I/O
Operating Properties	1 x RTC header
Operating temperature: 0°C to 50°C	1 x System fan header
Operating humidity: 0%-90% (non-condensing)	1 x LPC (80h) header
Non-operating temperature: -40°C to 70°C	1 x LVDS connector
Non-operating humidity: 0%-95% (non-condensing)	1 x USB 2.0 header
	1 x SATA power connector
CPU	1 x System power connector
Intel Atom processor E3815
Single core, 22nm	Rear I/O
1.46GHz	1 x RJ45
512KB cache	1 x USB 3.0
5W TDP	1 x USB 2.0
Socket	1 x DC-in
1 x BGA 1170	1 x MicroSD card slot 1 x Serial
Memory	1 x HDMI v1.4
1 x SO-DIMM slot	OS Supported
DDR3L memory Up to 8GB 1066Mhz	Windows 7 (x32/x64) Windows 8.1 (x32/x64) Android 4.4
Flash Memory	Fedora 20
4GB of eMMC memory	Power Supply
LAN	AC 100~240V
1 x GbE LAN port (Realtek RTL8111G)	12V DC-In
Video
Intel HD Graphics
SATA
1 x SATA II 3Gb/s port
