Features:

• Supports Intel Core i5 32nm processors
• 2 x DDR3 SO-DIMM(w/o ECC), up to 4GB
• Supports CRT,DVI and LVDS (dual display)
• 2 x Gigabit LAN
• 6 x SATA II, 10 x USB 2.0, 6 x COM
• 1 x Mini PCI-E
• Optional AMT, RAID
• Modular mechanism design provides flexible product configuration and easy maintenance.
• Optional panel with ultra high brightness and super dynamic contrast, along option with auto-brightness sensor offers application in day and night.

Specifications:



Panel	Cell Type / Glass Surface	TFT LCD / Black Anti-Glare, low reflection coating
	Aspect Ratio / Size	Wide / 46" viewable diagonal area
	Active Area / Pixel Pitch	1018.08(H) x 572.67(V) mm / 0.53(H) x 0.53(V) mm
	Native Resolution / Colors	1920(H) x 1080(V) / 16.7 Million
	Brightness / Contrast	450 cd/m2 (typ) / 5000 : 1
	Response Time	^ 8 ms (G-to-G)
	Viewing Angle (typical)	H. 178° (- 89° ~ + 89°) , V. 178°(- 89° ~ + 89°)
	Light Source	CCFL , Long life, 50,000 hrs (typ)
Input Sources	PC System	Signal	Analog RGB (0.7/1.0 Vp.p, 75 ohms)
		Sync	Separate Sync, Composite Sync, Sync On Green
		Frequency	Fh: 30 - 82Khz , Fv: 50 -75Hz
	Audio System	3W Amplifier
Input Terminals	1 x VGA (15 Pin Female D-Sub), 1 x PC Audio (Stereo Headphone Jack), 1 x AC Inlet
Convenient Features	Auto Calibration , Back Light Adjustment, Plug&Play (VESA DDC/CI, DDC 2B)
	OSD Multi-Languages , Wall Mount Ready (VESA 550 x 300 mm)
Power	Internal power supply with universal / Auto-Sensing, AC 90 to 260V, 50 / 60 Hz
Power Consumption	Operation / Power Saving	190 watt, < 2 watt (Support DPMS)
Operating Condition	Temperature / Humidity	0°C ~ 50°C (32°F ~ 122°F), 10% ~ 90% (no condensation)
Storage Condition	Temperature / Humidity	- 20°C ~ 60°C (- 4°F ~ 140°F), 10% ~ 90% (no condensation)
Certification		FCC,CE
Dimensions	Physical	With Flanges(W x H x D): TBD
		Without Flanges(W x H x D): 1132.0 x 671.0 x 39.5 (mm)
	Carton	W x H x D = TBD
Weight	N.W. / G.W.	38.0 Kgs/41.0 Kgs
Container Loaded	20ft / 40ft / 40ft HQ	TBD (Sets , By pallet)



System processor/Chipsets	Processor	Intel® Core™ i5 Celeron processors
		Socket G
	FSB	1066MHz
	Chipset	Intel® QM57
	BIOS	AMI
Memory	Technology	DDR3 800/1066 MHz SDRAM
	Max. Capacity	Up to 8GB DDR3 DRAM
	Socket	2 x DDR3 SO-DIMM
Audio	Controller	Realtek ALC662 HD CODEC
	Audio Interface	High Definition Audio
Display	Chipset	Intel® QM57 integrated HD Graphics
	Display Memory	Shared system memory up to 2GB
	Resolution	Analog Display: Up to 2048 x 1536
	LVDS	18/24bit, dual channel
	LVDS Resolution	Digital LVDS: Up to 1920 x 1200
	Dual Display	CRT+LVDS, CRT+DVI
Ethernet	Interface	Dual 10/100/1000 Mbps
	Controller	LAN1: Intel 82577LM, LAN2: Intel 82574L

See CDi5-QM57 for more details in Motherboard.
