Remote Console 32-ports CAT5 KVM w/ CAT5 Extenders

Combo Cat6 2-console KVM Benefits

• Combo Cat6 KVM with either 8, 16 or 32 ports in 1U
• Up to 40 meters between your servers & KVM ports
• Remote access up to 150 meters
• Cascade switches up to 8 levels & Mix switches between Cat6 & Combo DB-15 KVM
• Support DVI-USB, VGA-USB & VGA-PS/2 server interface
• Mix PS/2, USB & SUN with Multi-Platform switch capability



Switch Features & Options

• Multi lingual on screen display menu
• Advanced user profiles and configurable OSD hot key combinations
• Dual power with failover
• 12V, 24V and 48V DC Power options








Ordering Information

Console	Local	Remote		8-port	16-port	32-port
	1	1	0	NVCCE800	NVCCE1600	NVCCE3200

KVM Specification

■ KVM Port
Number of ports:	8, 16 or 32
Connector:	RJ-45
Connectivity:	DVI-D / VGA connector dongle up to 40 meters (132 feet) via Cat6 / Cat5 cable
■ Local Console
Graphic Connector:		1 x DB-15 VGA
Resolution:		Up to 1600 x 1200
Input device:		2 x USB type A for keyboard & mouse
Remote I/O:		RJ45 via Cat5 / Cat5e / Cat6 cable up to 150m
Compensation:		Auto adjust for cable length
Resolution support:		4:3 - max. 1600 x 1200 16:10 - max. 1440 x 900
■ Expansion:	Up to 256 servers by 8-level cascade
■ Compatibility
Multi-platform:	Mix PCs, SUN and Mac G3 / G4 Mac / iMac
Support:	Windows 7 / Vista / 2003 / XP, Linux, Unix

■ Power
Input:	Auto sensing 100 to 240VAC, 50 / 60 Hz OR AC / DC power adapter 12V@3.3A (optional)
Option DC:	12V / 24V / 48V DC input
Consumption:	Max. 48 Watt, Standby 5 Watt
■ Regulatory :
Safety:	cUL, FCC & CE certified
Environment:	RoHS2 & REACH compliant
■ Environmental
Operating:	0 to 50°C
Storage:	-5 to 60°C
Relative humidity:	90%, non-condensing
Shock:	50G peak acceleration (11ms, half-sine wave)
Vibration:	58-100Hz / 0.98G (11ms / cycle)
■ Product Information
Dimension (W x D x H):	443 x 171 x 44 mm / 17.4 x 6.7 x 1.73 inch
Net weight:	3 kg / 6.5 lb
■ Packing Information
Dimension (W x D x H):	500 x400 x90 mm / 19.7 x 15.7x3.5 inch
Gross weight:	5 kg / 11 lb

KVM port & Cat6 dongle connection

IF-DUSBD DVI-USB dongle
■ To connect DVI-D connector to the computer's video card
■ To connect USB connector to the computer's USB port


IF-DUSB VGA-USB dongle
■ To connect DB-15 connector to the computer's video card
■ To connect USB connector to the computer's USB port


IF-DPS2 VGA-PS/2 dongle
■ To connect DB-15 connector to the computer’s video card
■ To connect PS/2 keyboard connector to the computer’s keyboard port
■ To connect PS/2 mouse connector to the computer’s mouse port

* Requires the user to enable showing unsupported resolutions via the target computer's video adapter settings ( effectively ignoring the DDC / EDID )

Remote & Local console connection

KVM Cascade

■ Cascade up to 8 levels, 256 servers
■ Cascading multiple KVM with CBC-6 cascade cable
