LPC8800-i5
  • Overview
  • Download

LCP8800 has an unique Multi I/O (MIO) Expansion Layer that makes it easier to get the I/O configuration you need. From the main board there is also an I/O connector that fits with a plug-in I/O card which you can customize by choosing from a selection of ports you need - Audio, DI/DO, Serial, USB, LAN, and eSATA. There is also a drive bay area with SATA connectors for a 2.5” HDD or SSD. This connection can also be used to create an external CompactFlash socket.



Features

  • Intel Ivy Bridge Platform
  • Fanless
  • Multiple display ports
  • Up to 4GB DDR2 memory
  • Integrated SIM card reader
  • Expandable PCI or PCIe slot
  • Multi I/O Expansion Layer

Specification

Processor Options 3rd Gen Intel® Core™ i7/i5/i3
Chipset Intel® HM65
BIOS AMI 32bit SPI UEFI BIOS
System Memory Sockets 2 x 204-pin SODIMM socket
  Technology DDR3 1333/1600 MHz
Max. Capacity Up to 16 GB
USB 6x USB 2.0 compliant hosts: Type A connector
Expansion Bus 2x Mini-PCIe expansion sockets, one for PCIexpress 1x and USB 2.0 signals and the other is for USB 2.0 with SIM-card reader
OS Support Microsoft Window 7/7 Embedded/XP/XP Embedded, Linux 2.6.32 or later
Storage HDD/SSD Support 1x 2.5” HDD/SSD drive bay
Expansion 1xSATA port for 1x 2.5” SSD/HDD driver bay


Networking

LAN 2x10/100/1000Mbps, Autosensing,RJ-45
Controller Intel 82574L x2
Display



Graphics Controller Intel® HD Graphics 4000
Display Interface HDMI x1, VGA x1, DVI-D x1
Audio



Audio Controller Realtek ALC886
Audio Interface Phone Jack x2 for Mic-in and Line-Out
LEDs Power, HDD active
  Others External: Power-On Button, SMA Antenna Hole Internal: Reset
Physical
Characteristic
Housing (SECC) Sheet Metal
Weight TBD
Dimensions (WxHxD) 277x67x194mm
Mounting Options Wall mount -4
Environment Operation Temperature -20~55°C (with Industrial grade components)
Storage Temperature -20~70°C
Ambient Relative Humidity
(non-condensing)
5 to 95% (non-condensing)
Power Input Voltage +18~36Vdc
Power Consumption TBD
AC Adapter 75W 19V/3.95A
Standard and
Regulation
EMC CE/FCC
Green product RoHS
Reliability Alter tool Built-in buzzer and RTC (real-time clock) with battery lithium backup
Automatic Reboot Trigger Watchdog Timer 1~255 level time interval system reset, software programmable
Warranty 2 Years
MTBF TBD
