15" LCD Rugged Completely Sealed IP66 / NEMA4X Stainless Steel Chassis Mount, Water / Dust proof (Model: WCH1500C3-IP)

15" LCD Rugged Completely Sealed IP66 / NEMA4X Stainless Steel Chassis Mount, Water / Dust proof (Model: WCH1500C3-IP)

15" LCD Rugged Completely Sealed IP66 / NEMA4X Stainless Steel Chassis Mount, Water / Dust proof (Model: WCH1500C3-IP)

Inquiry/Quote Request
WCH1500C3-IP
  • Overview
  • Download




Features:
  • Enclosure: Completely sealed, IP65 (NEMA4) grade.
  • Widely used in chemical industry, food industry, medical devices, appliances etc. with good corrosion resistance.
  • Stainless Material:
    CNS JIS ASTM AISI DIM
    304 SUS 304 S30400 304 1.4301


Specifications:
Technical Description
Screen Size (diagonal) 15"
Active Display Area (mm) 304.1 (H) x 228.1 (V)
Pixel Pitch (mm) 0.297 (H) x 0.297 (V)
Native Display Resolution (pixels) 1024x768
Brightness (CD/m^2) 250 (typ.)
Contrast Ratio 500:1 (typ.)
Viewing Angles (L/R/U/D) -70~70 (H); -60~65 (V)
Number of Colors 16.2M (6bits+FRC)
Optional Touch Screen Resistive,Capacitive
Power Information
Power Source 12V DC in, with External AC to DC Adapter (100~240V AC)
Power Consumption(Normal operation) 25 W typical, normal operation
Power Input VESA DPMS Compliant
Display Signals
Plug & Play VESA DDC 1/2B
Video Input (optional) yes
*Due to Panel material's deviation, different panel supplier will set different specific variance range to optical characteristics. The factors of time used, Lamp current, Ambient temperature will influence the optical measurements.
