Membrane Keyboard with Touchpad (Model: DT-5K-MEM-TP)
- Overview
- Download
Features
The new DT-5K-MEM-TP is an industrial membrane keyboard built to withstand the harshest of environments. Modeled after iKey's popular 5K product line, this keyboard is manufactured with a hardcoated, textured polyester film and trampoline-mounted, snap-dome switches that provide a superior feel and actuation over a standard membrane keyboard. The integrated Synaptics touchpad is completely sealed under an extra layer of PVC membrane, which extends the life of the product. Since this keyboard lacks the crevices found between the keys of a regular keyboard, it is extremely durable and easy to clean. The DT-5K-MEM-TP is designed to meet NEMA 4X specifications, which means it can withstand directed hose water, disinfectants, environmental contaminants and heavy industrial use.
Specification
| Certifications | NEMA 4X;IP67;UL60950;FCC Part 15 Class B;CE |
| Shock | 3 x 11 ms pulses of 50g on each of 3 axes |
| Cable | LENGTH: 10 feet (3 meters) DESIGN: "Y" PS/2 Cable (providing separate keyboard and mouse connections), or Single-Cable USB |
| Key Switch | MATERIAL: Hardcoated Textured Polyester Film LIFE: Greater Than 2 Million Cycles TRAVEL: 0.020 in. (0.5mm) (Positively effected by Trampoline Mounting) ACTUATION FORCE: 9.88 oz +/- 1.06 oz (280g +/- 30g) FEEDBACK: Tactile with Mechanical Snap |
| Vibration | POWER SPECTRAL DENSITY: .04g/HZ FREQUENCY RANGE: 20Hz-2Khz DURATION OF TEST PER AXIS: 3 hours |
| Power | PS2: KEYBOARD: 40mA@5V (Keyboard port) TOUCHPAD: 10mA@5V (Mouse port) USB: 50mA@5V (CPU port) |
| Compatability | PS/2 KEYBOARD/TOUCHPAD: All Windows Operating Systems USB KEYBOARD/TOUCHPAD: All Windows and Macintosh OS |
| Temperature Range | STORAGE: -40C to +65C (-40F to +149F) OPERATING: 0C to +60C (32F to +140F) |
| Weight | 5.25 lbs +/- 0.10 lbs (2.39 kg +/- 0.05 kg) |
| Warranty | 1 year limited warranty |
| Humidity | 100% |
| Dimensions | 16.25" x 7.88" x 1.80" (w-h-d) 412.8mm x 200.2mm x 45.7 mm |
| Model Numbers | DT-5K-MEM-TP-PS2: With PS/2 Cable DT-5K-MEM-TP-USB: With USB Cable |
