Rubber Keyboard in Aluminum Backplate (Model: SL-89)
- Overview
- Download
Features
The SL-89 is a thin keyboard that features adjustable green backlighting that is also available in a night vision (NVIS) compatible configuration. It has integrated mounting holes and a right-angle USB cable that is 14.5" (0.4 m) in length when coiled. This keyboard is excellent for military applications. (Swedish layout shown in photo)
Specification
| Certifications | CE UL60950, FCC Part 15 Class B |
| Shock | 3 x 11 ms pulses of 50g on each of 3 axes |
| Cable | Right-Angle USB: 14.5" (0.4 m) coiled |
| Key Switch | MATERIAL: Industrial Silicone Rubber LIFE: Greater than 10 Million Cycles TRAVEL: 0.055 in. (1.4mm) A ACTUATION FORCE: 6.35 oz +/- 1.06 oz (180g +/- 30g) FEEDBACK: Tactile with Mechanical Snap |
| Vibration | POWER SPECTRAL DENSITY: .04g/HZ FREQUENCY RANGE: 20Hz-2Khz DURATION OF TEST PER AXIS: 3 hours |
| Power | USB: 200 mA@5V (from CPU port) |
| Temperature Range | STORAGE: -40C to +90C (-40F to +194F) OPERATING: -40C to +70C (-40F to +158F) |
| Weight | 2.0 lbs +/- 0.10 lbs (0.91 kg +/- 0.05 kg) |
| Warranty | 1 Year Limited |
| Humidity | 100% Humidity Resistant |
| Dimensions | 9.88" x 7.84" x 0.62" (w-h-d) 251.0mm x 199.1mm x 15.7mm |
