Industrial Keyboard with Integrated Trackball (Model: YK1800)
- Overview
- Specifications
- Download
The new YK1800 is constructed using a highly rugged, stainless steel case and industrial silicone rubber pad. The YK1800's trackball pointing device is a completely sealed 25-mm unit. The trackball is operated using sealed stainless steel switches with left, right and middle click functions. The YK1800 features integrated green LED backlighting for use in low-light environments, and is sealed to NEMA 4X specifications.
Features
- Integrated Backlighting
- Integrated Trackball
- PS/2 or USB configurations available
| CERTIFICATIONS | NEMA 4X, IP65 |
| SHOCK | 3x11 ms pulses of 50g on each of 3 axis |
| CABLE | LENGTH: 10 feet (3.05 meters) DESIGN: "Y" PS/2 Cable (providing separate keyboard and mouse connections), or USB cable |
| KEY SWITCH | MATERIAL: Industrial silicone rubber LIFE: Greater Than 10 Million Cycles TRAVEL: 0.055 in. (1.4 mm) ACTUATION FORCE: 7.05oz +/- 1.05oz (200g +/- 30g) FEEDBACK: Tactile with mechanical snap |
| VIBRATION | POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours |
| POWER | PS2: KEYBOARD: 200mA@5V (from Keyboard port) TRACKBALL: 20mA@5V (from Mouse port) USB: 220mA@5V (from CPU port) |
| COMPATIBILITY | PS/2 KEYBOARD/TRACKBALL: All Windows Operating Systems USB KEYBOARD/TRACKBALL: All Windows and Macintosh OS |
| TEMPERATURE RANGE | STORAGE: -40C to +85C (-40F to +185F) OPERATING: 0C to +65C (+32F to +149F) |
| Weight | 4.4 lbs +/- .10 lbs (1.8 1kg +/- .05 kg) |
| HUMIDITY | 100% Humidity Resistant |
| DIMENSIONS | 14.80" x 5.72" x 1.69" (w-h-d) (375.9 mm x 145.3 mm x 42.9 mm) |
