Panel Mount Keyboard with Emergency Key (Model: SLP-86-911-461)
- Overview
- Download
Features
Designed to meet MIL-STD-461 standards, the SL-86-911-461 is ideal for harsh environments where electromagnetic interference is a top concern.
In addition, the SL-86-911-461 features an emergency key that, when pressed, sends a signal of Shift+F1 and lights up for 30 seconds. The SL-86-911-461 integrates the HulaPoint II™, an upgraded pointing device that offers improved sensitivity and increased durability. It boasts a completely sealed and ruggedized construction that, when properly sealed, allows it to meet NEMA 4X specifications, ensuring that this keyboard is sealed against the elements or unwanted spills.
Specification
| Certifications | NEMA 4X, CE UL60950, FCC Part 15 Class B |
| Shock | 3x11 ms pulses of 50g on each of 3 axes |
| Cable | LENGTH: 4 feet (1.2 meters) DESIGN: "Y" PS/2 Cable (providing separate keyboard and mouse connections) |
| Key Switch | MATERIAL: Industrial Silicone Rubber LIFE: Greater than 10 Million Cycles TRAVEL: 0.055 in. (1.4mm) ACTUATION FORCE: 7.05 oz. +/- 1.06 oz. (200g +/- 30g) FEEDBACK: Tactile with Mechanical Snap |
| Vibration | POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours |
| Power | PS2: KEYBOARD: 250mA@5V (from PS2 port) |
| Flammability | PRINTED CIRCUIT BOARD: 94 VO SILICONE OVERLAY: 94 HB INTERFACE CABLE: 94 VO |
| Compatability | PS/2 KEYBOARD/HULAPOINT: All Windows Operating Systems USB KEYBOARD/HULAPOINT: All Windows and Macintosh OS |
| Temperature Range | STORAGE: -40C to +90C (-40F to +194F) OPERATING: -40C to +70C (-40F to +158F) |
| Weight | 1.75 lbs (0.79 kg) |
| Warranty | 1 year limited warranty |
| Humidity | 100% |
| Dimensions | 11.80" x 6.79" x 1.35" (w-h-d) 299.7mm x 172.5mm x 34.3mm CUTOUT: 10.40" x 5.40" (w-h) 264.2mm x 137.2 |
| Model Numbers | SLP-86-911-461-PS2: With PS/2 cable |
