42" Infrared Touchscreen, metal frame, with Anti Glare glass, 12mm touchscreen thickness, USB Controller. (Model: LIR4200MN5)

Product discontinues. Contact us at Info@iTechLCD.com for replacement item.

Overview

iTechLCD Infrared touchscreen is waterproof and maintenance free with highest transparency. The preferred solution for application, reliability and clarity. Leasingtouch technology combines superior optical performance with excellent gasket-sealing capabilities, so it's an excellent choice for harsh industrial and outdoor kiosk applications. Touched with a finger, gloved hand, fingernail, or stylus, it delivers a fast, accurate response every time. iTechLCD infrared technology is available for standard size and large size panel solutions.

Feature

Advantage
■ Withstands severe environments
■ Stable, no-drift calibration performance
■ Vandal- and abrasion-resistant screens, ideal for rugged applications
■ Parallax-free performance for LCD displays
■ Sealable against contaminants
■ Operable in various light conditions, indoor and outdoor

Application
■ Point-of-information kiosks
■ Vending and ticket sales
■ Electronic catalogs
■ Gaming, lottery, and amusement
■ Public pay phones
■ Multimedia marketing
■ Banking/financial transactions
■ Industrial control rooms
■ Computer-based training

Specifications

Size
General Size	12″ to 70″
Custom Size	10.4″ to 150″
Fit in with	Panel display device
Performance
Resolution(Interpolation)	4096*4096
Linearity Error	<1.5mm
Response Speed	<15ms
Mechanical
Frame Material	Carbon Steel
Input Method	Finger or gloved hand (rubber ,cloth or leather)
Touch Activation Force	No minimum touch activation force is required
Minimum Touch Object	6mm X 6mm for size under 22”
	8mm X 8mm for size above 22”
Vandal-proof	No break by 1-pound steel ball dropping from 130 cm high
Surface Durability	Surface durability is that of glass, Mohs\' hardness rating of 7
Optical
Light Transmission	90% Meet ASTM D1003
Environmental
Temperature	Operating Range: -20°C ~ 70°C;
	Storage Range: -40°C ~ 85°C
Relative Humidity	Operating Range: 0%~90% RH (no dew falls)
	Storage Range: 0% to 95% RH (no dew falls)
Altitude	Up to 3,000m
Ambient Light	Direct sunlight 90°to ±30° to the display surface Touch detection operational
	Direct sunlight all angles to display surface Free of false touch reports
Life Time	At least 10-years
Electrical
Operation Voltage	Typical +DC 5V, +4.75V to +5.25V
Power Supply	USB or PS/2 Interface for size under 55”; External power adaptor for size above 55”
Interface	Full Duplex USB 2.0 (Full Speed) Plug and play compatible
	Serial RS-232. Baud Rate: 9600, 8 Data Bits, 1 Stop Bit, No Parity
Current	Typical 150MA@+5VDC; 350mA, maximum
Power	<1.5W, operating current<300mA
Electrostatic Protection	15 kV air / 8 kV contact discharges (EN61000-4-2,1995 :Level 4)
Controller	Integration inside touch panel
Agency Approvals	CE, FCC, Rohs
Operation System	Linux/ Dos / Windows ME/95/98 / NT4.0/XP/2000/Mac OS
MTBF	Greater than 1,543,000 hours per MIL-HDBK-217-F2
