IP66 Flush Mount (OSD front) 24.1" LCD monitor, 1920 x 1200, LED 700 nits, VGA input (Model: EFPMF6-W2410HB)

IP66 Flush Mount (OSD front) 24.1" LCD monitor, 1920 x 1200, LED 700 nits, VGA input (Model: EFPMF6-W2410HB)

IP66 Flush Mount (OSD front) 24.1" LCD monitor, 1920 x 1200, LED 700 nits, VGA input (Model: EFPMF6-W2410HB)

Inquiry/Quote Request
EFPMF6-W2410HB
  • Overview
  • Download
EFPMF6 Series: Industrial Flush Mount Aluminum Housing LCD Monitor (Optional Integrated Projective Capacitive Touch screen/Front IP66/NEMA4x/Front and more...)




Features Highlights:

  • 1. FLASH MOUNT / FRONT MOUNTING
  • 2. Aluminum Housing Flush Mount Design
  • 3. AR Glass Protective Glass at front
  • 4. Optional High Brightness and Touch screen
  • 5. Front OSD


  • IP66 Water and Dust proof connection for a higher protection
  • All Connectors are facing backward


Features:
  • Modular mechanism design provides flexible product configuration and easy maintenance.
  • Optional to built-in touch screen for interactive application.
  • Available with auto-brightness sensor offers application in day and night.
  • IP66 Compliant
  • Able to protect against powerful water jets
  • Complete custom design/solution for OEM customers

Specifications:
Panel         Cell Type / Glass Surface TFT LCD / Black Anti-Glare, low refection coating
Aspect Ratio / Size Wide / 24.1" viewable diagonal area
Active Area / Pixel Pitch 518.4(H) x 324.0(V) mm / 0.27(H) x 0.27(V) mm
Native Resolution / Colors 1920(H) x 1200(V) / 16.7M
Brightness / Contrast 700 cd/m2 (typ) / 1000 : 1
Response Time ≤ 14ms (G-to-G)
Viewing Angle (typical) H.178o (- 89o ~ + 89o) , V. 178o(- 89o ~ + 89o)
Light Source LED backlight, Long life, 35,000 hrs (typ)
Input Sources     PC System Signal Analog RGB (0.7/1.0 Vp-p, 75 ohms)
  Sync Separate Sync, Composite Sync, Sync On Green
  Frequency Fh : 30 - 82Khz , Fv : 50 -75Hz
Audio System 2W speaker x 2
Input Terminals 1 x VGA (15 Pin Female D-Sub) , 1 x PC Audio (Stereo Headphone Jack) , 1 x DC Power Plug
Convenient Features   Auto Calibration , Back Light Adjustment , Plug&Play (VESA DDC/CI, DDC 2B)
OSD Multi-Languages , Wall Mount Ready (VESA Dimension - please refer to Drawing)
Power External AC-to-12VDC power adapter with universal / Auto-Sensing, AC 90 to 260V, 50 / 60 Hz
Power Consumption Operation / Power Saving 50 watt , < 1 watt (Support DPMS)
Operating Condition Temperature / Humidity 0oC ~ 50oC (32oF ~ 122oF) , 10% ~ 90% (no condensation)
Storage Condition Temperature / Humidity - 20oC ~ 60oC (- 4oF ~ 140oF) , 10% ~ 90% (no condensation)
Certification   FCC , CE
Dimensions   Physical Please refer to Drawing
Carton W x H x D = TBD
Weight N.W. / G.W. 12 Kgs / 13.5 Kgs
Container Loaded 20ft / 40ft / 40ft HQ

TBD (Sets , By pallet)



Options Touch Video / TV Enhanced Panel Others
Resistive touch SV + AV Panel with LED backlight Digital Signage(Stand alone)
Capacitive touch SV + AV + AV Looping High brightness panel Networking Digital Signage
SAW touch SV + AV + TV Wide Temperature Motion Sensor
Infrared touch   Sunlight Readable Light Sensor
Protected glass     Auto-Dimming


LCD Options
  LED Backlight

Introducing LED backlight options for monitors for energy efficiency and a brighter screen.

  VIDEO Input

For Video inputs options:
  • DVI
  • DVI+HDMI
  • SVideo+AV
  • SVideo+AV+DVI
  • AV+Looping
  • DVI+AV+Looping
  • HD-SDI



  Optical Bonding

  • Optical Bonding provides the best reduction of ambient light washout of any commercially available enhancement technology.
  • Optical Bonding has a lower cost than most other competing technologies.
  • Optical Bonding offers superior ruggedization, enhancing the display durability under vibration, shock and other environmental extremes.



  RS-232 Remote Control

Remote Control Protocol: Command Code to set system




  9-36V DC Input

iTech offers a selection of DC input from 9V to 36V.



  Light Sensor and Motion Sensor

iTech LCD offers Light and Motion Sensor

Privacy Filter
Front Glass Options:
- Anti Reflective AR Glass 3mm
- Anti Reflective AR Glass 6mm Vandal-Resistance
- Anti Reflective AR Glass 8mm Vandal-Resistance
- Anti Glare AG Glass 3mm
