| Specifications |
| |
| LCD Size |
15” |
| Max Resolution |
1024 x 768 |
| Brightness (cd/㎡) |
350 or 250 |
| Contrast Ratio |
700:1 or 600:1 |
| LCD Color |
262K or 16.7M |
| Pixel Pitch (mm) |
0.297(H) x 0.297(V) |
| Viewing Angle (H-V) |
140º / 125º or 160º / 160º |
| Backlight MTBF |
50,000 hrs (40,000 hrs) |
| CPU |
IntelR Dual Core Desktop Processor(E2160) 1.8GHz or others |
| Chipset |
Intel® 945G |
| I/O Ports and Switches |
1 x 12V/24V DC Input Jack
1 x PS/2
3 x RS-232 COM port
1 x RS-232/422/485 COM port
1 x RJ-12, 12V/24V Cash Drawer Port
1 x RJ-45 for GbE LAN
8 x USB 2.0
1 x Power Switch
1 x Reset Button
|
| SSD |
CF Type II |
| Watchdog Timer |
Software Programmable supports 1~255 sec. System reset |
| Audio |
AMP 1.5W+AMP 1.5W (Built-in Stereo Speakers) |
| Expansion |
1 x PCIe mini card
1 x Mini PCI Interface (Wireless LAN 802.11 a/b/g Module )
1 x Bluetooth module (USB interface, Bluetooth V2.0)
|
| HDD Drive Bay |
1 x 3.5” SATA HDD bay or 1 x 2.5” SATA HDD bay |
| Construction Material |
ABS + PC Plastic front frame |
| Mounting |
Panel, Wall, Stand and Arm (VESA 100mm x 100mm) |
| Front Panel Color |
Black or White |
| Dimension (WxHxD) (mm) |
363 x 322 x 80 |
| Operation Temperature |
0°C~45°C |
| Storage Temperature (℃) |
-20°C~80°C |
| EMC |
CE, FCC, CCC |
| Net Weight |
10.2 kg |
| IP Level(front panel) |
IP 64 |
| Safety |
UL, CB |
| Touch Screen |
Resistive Type 5-Wire (touch controller IC is on board) or Capacitive type touch screen without CF slot |
| Power Adapter |
ACE-D825AH: 252W
Input: 90VAC~264VAC @ 50/60Hz
Output:12VDC at 15A, 24VDC at 3A
|
| Power Consumption |
102 W |
| Camera |
2 Mega pixel with Autofocus |
|
|
| Ordering Information |
| |
| Part No. |
Description |
| AFL-315AB-945-E2160/WT-R/1GB-R11 |
15" 350cd/m² XGA panel PC w/ Dual-Core E2160 1.8GHz CPU,1GB DDR2 RAM,802.11 b/g wireless module,touch screen,2MP Camera,Bluetooth,black color,R11,RoHS |
| AFL-315ABE-945-E2160/WT-R/1GB-R11 |
15" 250cd/m² XGA panel PC with Dual-Core E2160 1.8GHz CPU, 1GB DDR2 RAM,802.11 b/g wireless module, touch screen, 2MP Camera, Blutooth, black color |
| AFL-315AW-945-E2160/WT-R/1GB-R11 |
15" 350cd/m² XGA panel PC w/ Dual-Core E2160 1.8GHz CPU,1GB DDR2 RAM,802.11 b/g wireless module,touch screen,2MP, Camera,Bluetooth,white color,R11,RoHS |
| AFL-315AWE-945-E2160/WT-R/1GB-R11 |
15" 250cd/m² XGA panel PC with Dual-Core E2160 1.8GHz CPU, 1GB DDR2 RAM,802.11 b/g wireless module, touch screen, 2MP, Camera, Blutooth, black color |
|
|
