| Specifications |
| |
| LCD Size |
15" |
| Max Resolution |
1024 x 768 |
| Brightness (cd/㎡) |
250 |
| Contrast Ratio |
600：1 |
| LCD Color |
262K |
| Pixel Pitch (mm) |
0.297(H) x 0.297(V) |
| Viewing Angle (H-V) |
160 /160 |
| Backlight MTBF |
50000 |
| CPU |
Intel® Atom processor N270 1.6GHz CPU |
| Chipset |
Intel® 945GSE + ICH7M |
| RAM |
Supports one 200-pin 2GB (Maximum) 400MHz or 533MHz DDRII SO-DIMM |
| I/O Ports and Switches |
1 x RJ-45 for RS232 COM Port
1 x RJ-45 for RS-232/422/485 COM port
1 x RJ-45 for Giga LAN
5 x USB 2.0 (4 in the rear, 1 in front panel)
2 x Power Switch (Inside Fornt Panel & Rear cover)
1 x Reset Button
1 x RJ12 for Digital Input / Output
1 x Terminal Block for 10~28VDC Input
1 x VGA Port |
| SSD |
CF Type II |
| Watchdog Timer |
Software programmable supports 1~255 sec. System reset |
| Audio |
AMP 2W+2W |
| Expansion |
1 x Wireless Lan Module (PCIe Mini Card, 802.11 b/g LAN Module)
1 x Bluetooth Module (USB Interface V2.0)
1 x Webcam & Mic Function |
| HDD Drive Bay |
1 x 2.5" SATA HDD bay or Option HSDPA Module |
| Construction Material |
ABS + PC Plastic front frame |
| LED Function |
1 x Power ON/OFF LED on Front Panel |
| Mounting |
Panel, Wall, VESA 75mm x 75mm / 100mm x 100mm |
| Front Panel Color |
Black/ White/ Gray |
| Dimension (WxHxD) (mm) |
385.7 x 330.7 x 55.5 |
| Operation Temperature |
0°C~40°C with HDD
0°C~50°C with CF Card or SATA interface 2.5"SSD HDD |
| Storage Temperature (℃) |
-20oC ~60oC |
| EMC |
CE, FCC, CCC |
| Net Weight |
2.8Kg |
| IP Level(front panel) |
IP64 |
| Safety |
CB |
| Touch Screen |
Resistive Type 5-Wire (Touch controller IC is on board) |
| Power Adapter |
P/N: 63000-FSP0601AD101C-746RS
Power: 60W
Input: 90VAC~264VAC, 50/60Hz
Output: 12VDC |
| Power Requirement |
10 ~ 28V DC-IN |
| Power Consumption |
49W |
| HSDPA Mobile Solution (Optional) |
1 x HSDPA Mobile Module (USB Interface) |
|
|
| Ordering Information |
| |
| Part No. |
Description |
| AFL-415AEB-N270/WT-R/1GB-R11 |
15" 250 cd/m², 1024x768 fanless In-Wall panel PC with Intel® Atom™ N270 1.6G CPU, 1GB DDR2 RAM, AT/ATX mode, 802.11b/g Wireless, Bluetooth, 300K Pixel Camera W/Microphone, Touch screen and 10-28VDC Wide Range, Black color, R11, RoHS |
| AFL-415AEW-N270/WT-R/1GB-R11 |
15" 250 cd/m², 1024x768 fanless In-Wall panel PC with Intel® Atom™ N270 1.6G CPU, 1GB DDR2 RAM, AT/ATX mode, 802.11b/g Wireless, Bluetooth, 300K Pixel Camera W/Microphone, Touch screen and 10-28VDC Wide Range, White color, R11, RoHS |
| AFL-415AEG-N270/WT-R/1GB-R11 |
15" 250 cd/m², 1024x768 fanless In-Wall panel PC with Intel® Atom™ N270 1.6G CPU, 1GB DDR2 RAM, AT/ATX mode, 802.11b/g Wireless, Bluetooth, 300K Pixel Camera W/Microphone, Touch screen and 10-28VDC Wide Range, Gray color, R11, RoHS |
|
|
