42 300cd/m2 1920 x 1080 FULL HD Panel PC with Intel® GM45 Platform (Model: AFL-642AE-GM45)

Overview
Download

Features

* 26” 1920 x 1200 FULL HD TFT LCD
* WiFi 802.11b/g/n connection
* Built-in two speakers
* Built-in Bluetooth technology rids systems of cables and allows wireless
* connection to peripheral devices like head phones, printers, barcode readers or game controllers
* The Ambient Light Sensor helps conserve energy
* VESA-mountable for flexibility in mounting and deployment
* SAW touch screen with durable glass construction is perfect for healthcare, retail and hospitability applications (Optional)
* CD/DVD Combo and Blu-ray Drive for option

Specifications

LCD Size	42"
Max Resolution	1920 x 1080
Brightness (cd/㎡)	500
Contrast Ratio	2500:1
LCD Color	16.7M
Pixel Pitch (mm)	0.4845(H) x 0.4845(V)
Viewing Angle (H-V)	178º/178º
Backlight MTBF	60000
SBC Model	AFLMB2-GM45-R10
CPU	Celeron® M575 2.0GHz/ Core.2 Duo T7500 2.2GHz /Core™2 Duo T9400 2.53GHz
Chipset	Mobile Intel® GM45
RAM	Supports two 2GB (Maximum) 533MHz/ 667MHz DDRII SODIMM
I/O Ports and Switches	1 x RS-232 COM Port 1 x RS-232/422/485 COM port 2 x RJ-45 for Giga LAN 4 x USB 2.0 1 x Power Switch 1 x Reset Button 1 x HDMI Port 1 x Audio Port 1 x VGA Port
SSD	CF TypeII
Watchdog Timer	Software programmable supports 1~255 sec. System reset
Audio	AMP 10W + 10W
Expansion	1 x Wireless 802.11 b/g/n Lan Module (Mini PCIe Interface) 1 x Bluetooth Module (USB Interface)
HDD Drive Bay	1 x 2.5" SATA HDD bay
Construction Material	Metal front frame
LED Function	1 x Power ON/OFF LED on Front Panel
Mounting	Wall, Stand and Arm VESA 400mm x 200mm
Front Panel Color	Black C
Dimension (WxHxD) (mm)	990 x 582 x 135
Operation Temperature	0ºC ~40ºC With HDD 0ºC ~45ºC With CF Card or SATA interface 2.5" SSD HDD
Storage Temperature (℃)	-20ºC ~60ºC
Net Weight	35 Kg
IP Level(front panel)	IP64
Touch Screen	Surface Accoustic Wave Type (optional)
Smart OSD	1. OSD Keypad below the Front Panel 2. Remote Control for OSD Function
Power Requirement	100VAC~240VAC, 50/60Hz
Power Consumption	260 W
ODD Drive Bay	CD/DVD Combo Drive Blu-Ray Drive (Optional)
HSDPA Mobile Solution (Optional)	1 x HSUPA Mobile Module (USB Interface)

Ordering Information

Part No.	Description
AFL-642AE-GM45-CM575/WT-S/(OD)/1G/*(HU01)-R10	42" 500cd/m2 1920 x 1080 panel PC with CeleronR M 575 2.0GHz CPU, 1GB DDR2 RAM, 802.11 b/g/n wireless module, SAW touch screen, Bluetooth, RoHS
AFL-642AE-GM45-T7500/WT-S/(OD)/2G/*(HU01)-R10	42" 500cd/m2 1920 x 1080 panel PC with Core.2 Duo T7500 2.2GHz CPU, 2GB DDR2 RAM, 802.11 b/g/n wireless module
AFL-642AE-GM45-P8400/WT-S/(OD)/2G/*(HU01)-R10	42" 500cd/m2 1920 x 1080 panel PC with Core.2 Duo P8400 2.26GHz CPU, 2GB DDR2 RAM, 802.11 b/g/n wireless module
AFL-642AE-GM45-P8400/WT-S/(OD)/2G/*(HU01)-R10	42" 500cd/m2 1920 x 1080 panel PC with Core.2 Duo T9400 2.53GHz CPU, 2GB DDR2 RAM, 802.11 b/g/n wireless module
AFL-642AE-GM45-CM575/W/(OD)/1G/*(HU01)-R10	42" 500cd/m2 1920 x 1080 panel PC with CeleronR M 575 2.0GHz CPU, 1GB DDR2 RAM, 802.11 b/g/n wireless module, Bluetooth, RoHS
AFL-642AE-GM45-T7500/W/(OD)/2G/*(HU01)-R10	42" 500cd/m2 1920 x 1080 panel PC with Core.2 Duo T7500 2.2GHz CPU, 2GB DDR2 RAM, 802.11 b/g/nn wireless module, Bluetooth, RoHS
AFL-642AE-GM45-P8400/W/(OD)/2G/*(HU01)-R10	42" 500cd/m2 1920 x 1080 panel PC with Core.2 Duo P8400 2.26GHz CPU, 2GB DDR2 RAM, 802.11 b/g/n wireless module, Bluetooth, RoHS
AFL-642AE-GM45-T9400/W/(OD)/2G/*(HU01)-R10	42" 500cd/m2 1920 x 1080 panel PC with Core.2 Duo T9400 2.53GHz CPU, 2GB DDR2 RAM, 802.11 b/g/n wireless module, Bluetooth, RoHS

Packing List

1 * Power Cord (P/N:32000-000002-RS )	1 * IR Remote Controller (P/N:7Z000-8T00322ICP01G-RS )
1 * User's Manual CD-ROM	2 * Antennas (For 42” AFOLUX PPC) (P/N:32500-004000-RS)
