19" Super High Performance All in One Medical Panel PC (Model: EMPC1900D)

The Perfect Bedside Entertainment Terminal
The high-performance preinstalled Intel® Core™ 2 Duo support makes the EMPC-D series strong platform for bedside entertainment applications. The 17" and 19" LCD size enables clear display for all information. With the support of Intel® Core™ 2 Duo, the EMPC-D series are able to display superior image quality, perfect for entertainment applications. The strong capability of wireless 802.11 a/b/g/n connection brings more efficient data transmission advantage for bedside applications. The preinstalled bluetooth conveniently Communicates with some peripheral devices, such as keyboards, headsets and mice, providing perfect wireless environment for bedside entertainment.

Features

•	17", 19" medical panel PC for clinical review applications
•	High performance Intel® Core™ 2 Duo® CPU support
•	Upgraded Windows® Vista™ operating system support
•	User-friendly touch screen
•	Advanced 802.11a /b/ g/ n wireless network advantage
•	Preinstalled bluetooth module for powerful connectivity

		Powerful Processing Capability The EMPC-D series are supported by Intel® Core™ 2 Duo processor. The high performance feature enables complex data processing, perfect for bedside entertainment applications.
		Best Image Display Quality With the support of Windows® Vista™ operating system, the EMPC-D series have superior image processing capability. The upgraded functions of Windows® Vista™ make data processing more efficient and more secure.
		Value-Added Network Connection Advantage The EMPC-D series systems each have two Gigabit Ethernet LAN connectors and wireless 802.11a/b/g/n network connections, enabling better link quality through accurate network selection. The powerful 802.11 a/b/g/n/ Wireless connection increases redundancy and ensures reliable network for real-time medical record processing.
		Bluetooth Module for Perfect Connections The preinstalled IEI bluetooth module provides a wireless connection to a wide variety of peripheral devices, including headsets, keyboards and mice. High speed data transmission through the USB 2.0 interface is perfect for data processing.
		Reliable Touch Screen Design The EMPC-D series are equipped with reliable 5-wire resistive type touch screen. The touch screen makes medical order entry much easier when used as an information terminal.
		IP 64 Front Panel for Best Reliability The EMPC-D series are designed with IP 64 dustproof and waterproof front panel, allowing easy cleaning with disinfectant Without harming the panel itself.

Specifications

Model	EMPC1700D	EMPC1900D	Model	EMPC1700D	EMPC1900D
LCD size (inch)	17"	19"	Touch screen	Resistive 5-wire (RS-232 interface)
CPU	Intel® Core™ 2 Duo Socket P (T7500-2.2G / Celeron® M 550-2.0G)		Speakers	2 x 3W AMP
Chipset	Intel® GME965 + ICH8M		Wireless (Mini PCIe interface)	802.11 a/b/g/n Intel® 4965
RAM	2 x 2.0 GB (max.) DDR2 SO-DIMM (system max. 4.0 GB)		Bluetooth (USB interface)	Yes
Resolution	1280 x 1024		IP level	IP64 on front panel
Drive Bay	1 x 2.5 SATA HDD 1 x IDE CF card		OSD Function	Five buttons (LCD On/off, Light +,-, Audio +,-)
Power In	DC 12V input		LED Function	One front panel power on/off LED
Power Adapter	Medical Grade, AC 100V~240V input to DC 12V output		Safety & EMI	UL60601-1, EN60601-1, CCC, CE(EN60601-1-2), FCC Parts 18
I/O Ports	4 x USB 2.0 2 x RS-232 2 x Gigabit Ethernet (GbE) 1 x VGA 1 x Audio 1 x SATA 1 x Power inlet connector		Operation Temperature	0°C ~ 40°C
			Dimensions (W x H x D) (mm)	428 x 350 x 76	470 x 383 x 78
			Net Weight (kg)	6.6	7.0

Ordering information

Part No.	Description
EMPC1700D	17" medical panel PC, with Intel® Core™ 2 Duo 2.2GHz (T7500) CPU, 2GB DDR2 SO-DIMM RAM, 80GB SATA HDD, wireless 802.11 a/b/g/n, Bluetooth, touch screen and AC to DC power adapter, RoHS
EMPC1700D	17" medical panel PC, with 2.0 GHz Celeron® M CPU (Celeron® M 550), 2GB DDR2 SO-DIMM RAM, 80GB SATA HDD, wireless 802.11 a/b/g/n, Bluetooth, touch screen and AC to DC power adapter, RoHS
EMPC1900D	19" medical panel PC, with Intel® Core™ 2 Duo 2.2GHz (T7500) CPU, 2GB DDR2 SO-DIMM RAM, 80GB SATA HDD, wireless 802.11 a/b/g/n, Bluetooth, touch screen and AC to DC power adapter, RoHS
EMPC1900D	19" medical panel PC, with 2.0 GHz Celeron® M CPU (Celeron® M 550), 2GB DDR2 SO-DIMM RAM, 80GB SATA HDD, wireless 802.11 a/b/g/n, Bluetooth, touch screen and AC to DC power adapter, RoHS

Optional Mounting Kit

Wall Mount Kit	AFLWK-19
ARM	ARM-11-RS, ARM-31-RS
STAND	STAND-A19, STAND-B19
