Open Frame, 24.1" LCD monitor, 1920 x 1200, LED 400 nits, VGA+DVI+HDM w/ Resistive Touch (Model: EOPW2400-TR)

Open Frame, 24.1" LCD monitor, 1920 x 1200, LED 400 nits, VGA+DVI+HDM with 5 Wire Resistive Touch Screen and USB Controller

Open Frame, 24.1" LCD monitor, 1920 x 1200, LED 400 nits, VGA+DVI+HDM with 5 Wire Resistive Touch Screen and USB Controller

Inquiry/Quote Request
EOPW2400-TR
  • Overview
  • Specifications
  • Download
Experience unparalleled clarity and versatility with the 24-Inch Open Frame LCD Monitor EOPW2400-TR by iTech. Designed for seamless integration into a variety of applications, this high-performance display offers exceptional image quality and reliability. Whether for industrial, commercial, or professional use, the EOPW2400-TR is engineered to meet the demands of any environment, providing a robust solution for your display needs. Explore the advanced features and superior design that make the EOPW2400-TR the perfect choice for your next project.


Features:
  • 1920 x 1200 Native resolution, 400 cd/m2 brightness, 178° horizontal/vertical viewing angles
  • Modularize mechanical design provides flexible product configuration and easy maintenance
  • Optional build-in touch screen for interactive application
  • Optional panel with ultra high brightness and super dynamic contrast, along option with auto-brightness sensor offers application in day and night
  • Auto Power On: Monitor is always "ON" when connect to power.
  • Auto Video Signal On: Monitor (Backlight) will turn off when no video signal, but it will Auto turn back on.
Panel Cell Type / Glass Surface TFT LCD / Black Anti-Glare, low refection coating
Aspect Ratio / Size Wide / 24" viewable diagonal area
Active Area / Pixel Pitch 520.4(H) x 374.4(V) mm / 0.27(H) x 0.27(V) mm
Native Resolution / Colors 1920(H) x 1080(V) / 16.7M
Brightness / Contrast 400 cd/m2 (typ) / 1000 : 1
Response Time ^ 6 ms (G-to-G)
Viewing Angle (typical) H. 178° (- 89° ~ + 89°) , V. 178°(- 89° ~ + 89°)
Light Source LED backlight, Long life, 35,000 hrs (typ)
Input Sources PC System Signal Analog RGB (0.7/1.0 Vp-p, 75 ohms)
Sync Separate Sync, Composite Sync, Sync On Green
Frequency Fh : 30 - 82Khz , Fv : 50 -75Hz
Audio System 3W Amplifier
Input Terminals VGA+DVI+HDMI, 1 x PC Audio (Stereo Headphone Jack), 1 x AC Inlet
Convenient Features Auto Calibration , Back Light Adjustment , Plug&Play (VESA DDC/CI, DDC 2B)
OSD Multi-Languages , Wall Mount Ready (VESA 100 x 100 mm)
Power Internal power supply with universal / Auto-Sensing, AC90 to 260V, 50/60 Hz
Power Consumption Operation / Power Saving 110 watt, < 5 watt (Support DPMS)
Operating Condition Temperature / Humidity 0°C ~ 50°C (32°F ~ 122°F) , 10% ~ 90% (no condensation)
Storage Condition Temperature / Humidity - 20°C ~ 60°C (- 4°F ~ 140°F) , 10% ~ 90% (no condensation)
Certification   FCC , CE
Dimensions Physical With Flanges(W x H x D): 578.0 x 390.4(screw-to-screw) x 91.0 (mm)
Carton W x H x D = TBD
Weight N.W. / G.W. 12 Kgs / 13.5 Kgs
Container Loaded 20ft / 40ft / 40ft HQ TBD (Sets , By pallet)
