10'' 4:3 LED Open frame loose kit module, LCD panel, Inverter, OSD, LVDS, AToD board, DC adapter,VGA Input w/ 5 Wire Resistive Touch and USB Controller (Model: TSK1000-TR)

10'' 4:3 LED Open frame loose kit module, LCD panel, Inverter, OSD, LVDS, AToD board, DC adapter,VGA Input w/ 5 Wire Resistive Touch and USB Controller (Model: TSK1000-TR)

10'' 4:3 LED Open frame loose kit module, LCD panel, Inverter, OSD, LVDS, AToD board, DC adapter,VGA Input w/ 5 Wire Resistive Touch and USB Controller (Model: TSK1000-TR)

Inquiry/Quote Request
TSK1000-TR
  • Overview
  • Download

Features:
  • VGA Input
  • Optional RCA Composite Video + Speaker
  • Optional 5-Wire Resistive / Capacitive / SAW Touch supports all Windows / Linux OS
  • 4:3 Screen LED Back-Light 250nits


Specifications:
Screen Size 10" Diagonal)
Outline Dimension 215.5 x 166.5 x 5.0 (Typ.)
Display area 202.752 (H) x 152.064 (V)
Number of Pixel 1024 RGB (H) x 768(V)
Pixel pitch 0.198(H) x 0.198(V)
Pixel arrangement RGB Vertical stripe
Display mode Normally white
Surface treatment Antiglare, Hard-Coating (3H)
Weight 330 (Typ.)
Back-light Single LED (Side-Light type)
Power Consumption
Logic System 0.75 (Max.)
B/L System 2.64 (Max.)
