Rack PDU CMS-16DC : Telnet & Asynchronous (RS-232) Console Manager, 16-Port Unit, -48V DC (Model:CMS-16DC )

Rack PDU CMS-16DC : Telnet & Asynchronous (RS-232) Console Manager, 16-Port Unit, -48V DC (Model:CMS-16DC )

Rack PDU CMS-16DC : Telnet & Asynchronous (RS-232) Console Manager, 16-Port Unit, -48V DC (Model:CMS-16DC )

Inquiry/Quote Request
CMS-16DC
  • Overview
  • Download

Product discontinues. Contact us at Info@iTechLCD.com for replace items.

CMS-Series Telnet and Dial-Up Console/Aux Port Switch
*Product End-of-Life Notice: Contact WTI For Replacement Models*
CMS Series Console Port Management Switches provide secure, in-band and/or out-of-band access to RS232 console ports and maintenance ports on UNIX servers, routers, and other network equipment. System Administrators can access remote devices in order to change configuration parameters, connect users to restricted ports, collect buffered data, and perform a variety of other administrative tasks. The CMS is ideal for colocation applications; two different password security levels protect access to restricted ports and configuration commands. Users are allowed to connect to only the ports provided by their passwords, while supervisors are allowed to connect to any port or invoke configuration commands.


Intelligent Port Selection
Each port can be individually accessed by number, name, or group. Ports can be individually configured using simple, menu driven commands to set passwords, data rates, parity, flow control and many other operating parameters. The full matrix capability of the CMS allows any port to connect to any other port on the switch. Ports can also be connected or disconnected by a third party with supervisor rights. For example, systems managers can swap various RS232 devices between ports on a terminal server at a remote location. Configuration and Status screens display port parameters and connection activity for one or all ports.

Security and Co-Location Features
Address-specific IP security masks prevent unauthorized access to the CMS menu via network. Two levels of operational passwords are also available; the System Administrator level and the User level. The System Administrator level is used to configure the unit, assign passwords and access privileges, and create connections to any port. The User level allows connections only to assigned ports. The User level is ideal for co-location applications, as users can only view status and connect to ports assigned to their password.

Capture Buffer
The "Buffer Mode" feature allows individual ports to capture and store incoming data. This "snapshot" of the last 32K of received data is stored in non-volatile memory, and can be viewed, saved or erased by the system administrator at any time. This is particularly useful in the event that alarm information or other critical data is sent to a specific port during non-connect periods.



Features:
  • 8 or 16 RS232 DB-9 Serial Ports>
  • 10Base-T Ethernet Port
  • Modem Auto-Setup Command Strings (User Definable)
  • IP Security Features
  • Syslog Reporting
  • SNMP Capability
  • Menu Driven or Discrete TCP Port Connections
  • No Software Required
  • Non-Connect Port Buffering
  • Up to 17 Simultaneous Inbound Telnet Connections
  • Co-Location Features
  • Any-to-Any Port Switching
  • Port-Specific Password Protection
  • Data Rate Conversion, 300 to 115K bps
  • No Software Required
  • Easy-to-Use Menu/Commands
  • AC and 48V DC Powered Models
  • Sun Solaris Ready!
Applications:
  • Local or Remote Multi-Console Port Switching
  • UNIX Serial Console Management
  • Telnet or Dial-Up Access to Consoles at Remote Locations
  • Manage Multiple Console Ports Using a Single VT100 Terminal or PC
  • In-Band/Out-of-Band Network Management

Technical Specifications CMS-8 CMS-8DC CMS-16 CMS-16DC
Interface Descriptions:
Network Interface:
10Base-T Ethernet, RJ45
Multi-Session:
Discrete TCP Port Numbers		 Up to 9 Up to 9 Up to 17 Up to 17
RS-232 Interface:
Connectors:
DB-9M Connectors (DTE Pinout)		 8 8 16 16
Coding:
7/8 Bits, Even/Odd/No Parity, 1, 2 Stop Bits
Flow Control:
XON/XOFF, RTS/CTS, Both, None
Rate:
300 bps to 115,200 bps
Operation:
Timeout:
No Activity Disconnects Port/Modem Session:
None, 1, 5, 15, 30 Seconds
None, 1, 5, 15, 30, 90 Minutes
Memory:
Stores Parameters and Captured Data.
Non-Volatile.		 512K
Static		 512K
Static		 512K
Static		 512K
Static
Break:
Pass Break or Inhibit Break
Site ID:
32 Characters
Port Name:
16 Characters per Port
Passwords:
16 Characters per Port (Case Sensitive)
LEDs:
Power ON, Ready, Net, Data Activity 		1-8 1-8 1-16 1-16
Power:
AC Model:
IEC-320 Inlet, 115/230 VAC, 50/60 Hz, 5 Watts
DC Model:
Terminal Strip (#6-32), -48 VDC, 0.2 Amp Max.
Physical/Environment:
Dimensions:
1.75" High by 17" Wide by 6.8" Deep
(19" Wide with Rack Mounts Included)
Dimensions:
2.8" High by 17" Wide by 6.8" Deep
(19" Wide with Rack Mounts Included)
Weight:
8 lbs. Shipping Weight
Operating Temperature:
32°F to 122°F (0°C to 45°C)
Humidity:
10 to 90% RH, Non-Condensing
Venting:
Side Vents, Dissipates 12 Watts Maximum
Agency Approvals:
UL, cUL, CE, TUV, FCC Class A, RoHS Compliant
CE, FCC Class A, RoHS Compliant
