Plastic case, 17" LCD monitor, 1280 x 1024, 420 nits-w/ Capacitive Touch with USB (Model: EP1700HB-TC)

Plastic case, 17" LCD monitor, 1280 x 1024, 420 nits-w/ Capacitive Touch with USB (Model: EP1700HB-TC)
  • Front View
  • Front View
  • Front View
  • Side View
  • Side View
  • Back View
  • Accessories View

Plastic case, 17" LCD monitor, 1280 x 1024, 420 nits-w/ Capacitive Touch with USB (Model: EP1700HB-TC)

Inquiry/Quote Request
EP1700HB-TC
  • Overview
  • Download

Features:
  • Elegant design with slim bezel.
  • Integrated amp and stereo speakers give you a complete multimedia experience.
  • Long lasting product cycle-enclosure controlled, future generation panels phased-in without external changes.

Specifications:

Panel Cell Type / Glass Surface TFT LCD / Black Anti-Glare, low reflection coating
Aspect Ratio / Size 4:3/ 17" viewable diagonal area
Active Area / Pixel Pitch 337.92(H) x 270.34(V) mm / 0.264(H) x 0.264(V) mm
Native Resolution / Colors 1280(H) x 1024(V) / 16.7 Million
Brightness / Contrast 420 cd/m2 (typ) / 800 :1
Response Time g 5 ms
Viewing Angle (typical) H. 160° (- 80° ~ + 80°) , V. 160°(- 80° ~ + 80°)
Light Source CCFL , Long life, 50,000 hrs (typ)
Input Sources PC System Signal Analog RGB (0.7/1.0 Vp.p, 75 ohms)
Sync Separate Sync, Composite Sync, Sync On Green
Frequency Fh: 30 - 82Khz , Fv: 50 -75Hz
Audio System 2W speaker x 2
Input Terminals 1 x VGA (15 Pin Female D-Sub), 1 x PC Audio (Stereo Headphone Jack), 1 x AC Outlet
Convenient Features Auto Calibration , Back Light Adjustment, Plug&Play (VESA DDC/CI, DDC 2B)
OSD Multi-Languages , Wall Mount Ready (VESA 75 x 75 mm)
Power Internal power supply with universal / Auto-Sensing, AC 90 to 260V, 50 / 60 Hz
Power Consumption Operation / Power Saving 30 watt, < 2 watt (Support DPMS)
Operating Condition Temperature / Humidity 0°C ~ 50°C (32°F ~ 122°F), 10% ~ 90% (no condensation)
Storage Condition Temperature / Humidity - 20°C ~ 60°C (- 4°F ~ 140°F), 10% ~ 90% (no condensation)
Certification   FCC,CE
Dimensions Physical With Base(W x H x D): 374.5 x 366.7 x 183.0 mm
Without Base(W x H x D): 374.5 x 322.2 x 49.6 mm
Carton WxHxD= 416 x425 x142 mm
Weight N.W. / G.W. 5.0 Kgs / 6.0 Kgs
Container Loaded 20ft / 40ft / 40ft HQ 1040 / 2160 / NA (Sets , By pallet)

Options Enhanced Panel Video / TV Others
Panel with LED backlight DVI Digital Signage(Stand alone)
High brightness panel HDMI Motion Sensor
Wide Temperature SV + AV + TV Light Sensor
Sun Light Readable   Auto-Dimming
