WRPSD5284

5U Rackmount 2 x 8.4" LCD with SDI input and loop out via BNC. Up to 100M(HD-SDI)/300M(SD-SDI). (Model:WRPSD5284)
  • Front View
  • ISO Front View
  • Rear View
  • OSD
  • Input/Output
  • Accessories

5U Rackmount 2 x 8.4" LCD with SDI input and loop out via BNC. Up to 100M(HD-SDI)/300M(SD-SDI). (Model:WRPSD5284)

Inquiry/Quote Request
WRPSD5284
  • Overview
  • Download
Specification
Model Name WRPSD5284
Screen Size 8.4"
Active Area 170.4 (H) x 127.8 (V)
Pixel Pitch (mm) 0.213 (H) x 0.213 (V)
Display Resolution (pixel) 800x600
Contrast Ratio 250:1 (typ.)
Display Color 262,144 (6bits/color)
Brightness (CD/m^2) 350 (typ.)
Viewing Angle (CR>=10) 100 (H); 90 (V)
I/O
SDI input 1 x via BNC Connector
SDI Loop output 1 x via BNC Connector
VGA input 1 x 15 pin D-sub
DVI input 1 x DVI-D,Single-Link
S-Video input 1 x via 4 pin Mini-DIN
Composite input 1 x via RCA Connector
Supported Mode
SD-SDI (Standard-Definition-SDI) 480i /525i /576i /625i
480p/525p/576p/625p
HD-SDI (High-definition-SDI) 720p/1080i
Long distance signal transmission
SD-SDI signal 300M
HD-SDI signal 100M
PC Video Modes VGA,SVGA
Video Modes NTSC/PAL(auto-detected)
Signal Processing 8/10 bit
Tally LED Three color Tally LED
Power input 12VDC
Picture Mode
Scaling 1:1 / Fill / Aspect
Picture in Picture Position/Size/Swap Setting
Picture by Picture Side by Side split screen display
