High resolution Video Wall controller, All HDMI Connectors Carry with Audio Signal and HDCP Supported (Model: V2200HDMI)

Features

• iNDS unique GeniMask™ bezel masking technology
• Support up to 1920 x 1200 input content
• 1 x Full Screen HDMI output and 1 set of 2x2 HDMI output
• Output timing 480i/480P/720i/720P/1080i/1080P
• Support multiple display modes, such as full mode, clone mode, and User mode etc.
• Audio output via HDMI cable and extra 1 x 7.1 analog Channels, 1 x SPDIF output
• Allow remote manage the VWBOX via RJ-45, RS-232 cable or USB cable

Specifications

Model			V2200HDMI
Dimensions (mm)			156 x 169 x 60(W x D x H)
Cooling			Internal Fan
Front Panel	LED Light		6 x LED (1 x Input, 4 x Output, 1x Power)
	Keypad		6 Keys
	IR Receiver		Yes
Rear Panel	Input
	Output	Video	1xHDMI for Full Screen , 1 Set of 2x2 HDMI output (HDCP Supported)
		Audio	7.1 channels Analog output via 9 pins connector, 1XSPDIF connector
	Remote Connector		1X RS232(Via RJ-45 Connector), 1xRJ45( for Ethernet), 1X mini USB
Resolution			Clone, Full, Vertical Replication ,PIP and User Mode
			Input		Output
			Up to 1920 x 1200		720P/1080P
			640 x 400 @ 70 ,
			720 x 400 @ 70 ,85,,
			640 x 480 @ 60 , 66 , 70, 72, 75,
			800 x 600 @ 56 , 60 , 66, 70, 72, 75,
			1024 x 768 @ 60, 66, 70, 72, 75
			1280 x 720 @60
			1280 x 768 @60
			1360 x 768 @ 60
			1366 x 768 @ 60
			1152 x 864 @ 75
			1280 x 960 @ 60
			1280 x 1024 @ 60, 70 ,75
			1600 x 1200 @ 60
			480i/P
			720i/P
			1080I/P
			1920 x 1200 @ 60
Power Consumption
Power Supply	Connector		DC Power Jack
	Input		90VAC to 264VAC/47Hz to 63Hz
	Output		12V DC
OSD Function			1. Power On/Off	2. Output resolution selection	3 . GeniMask bezel masking control
Temperature			0ºC ~ 40ºC
Safety and Emission			CE, FCC, and CCC
